Raspberry PI 2D Barcode Scanner Module QR Code Reader for ATM

FOB Reference Price:Get Latest Price
  • 1 - 10
    US $125.00
  • 11 - 50
    US $120.00
  • >=51
    US $115.00
Supply Ability:
2000 Piece/Pieces per Week we have stock barcode scanner
Port:
Shenzhen Port
Report Suspicious Activity
Overview
Quick Details
Products Status:
Stock
Type:
Barcode Scanner
Scan Element Type:
CMOS
Colour Depth:
32 Bit
Interface Type:
USB, RS232
Max Paper Size:
A4
Optical Resolution:
2500
Scan Speed:
up to 300 scans/sec
Brand Name:
RAKINDA
Model Number:
RD4500I-003
Place of Origin:
Guangdong, China (Mainland)
Item name:
Raspberry PI 2D Barcode Scanner Module QR Code Reader for ATM
Depth of Scan Field:
40 mm ~ 235 mm
Supply Voltage:
DC 3.3±0.3V
interface:
USB,RS 232
Dimension:
71mm(L) X 61mm (W) X 50mm(H)
Weight:
300g
Operate Temperature:
-10℃ to + 50℃
image sensor:
752 x 480 CMOS
scan window:
38.3mm*60.4mm
Notification:
Beep
Packaging & Delivery
Packaging Details
barcode scanner+USB/RS232 Cable+ Power Adaptor(for RS232 only).
normal craft paper and foam.
Raspberry PI 2D Barcode Scanner Module QR Code Reader for ATM
Delivery Time
within 5 days after receiving the balance
Product Information

Product name: Raspberry PI 2D Barcode Scanner Module QR Code Reader for ATM

Item number: RD4500I

Interface: RS-232 (9.6~115.2Kbps) / USB 1.1 (HID-KBW,HID-POS)

Product size: 71mm(L) X 61mm (W) X 50mm(H)

Symbols: 1D&2D

Operating temperature: -10℃±50℃

Application: Access Control System, Kiosk, Turnstile, ATM, Vending Machine, Ticketing Machine, etc.

Product Shows

Raspberry PI 2D Barcode Scanner Module QR Code Reader for ATM

Technical Specifications



 Product name OEM 2D Barcode Scanner Module
 Item number RD4500I
 Processor  IOTC 0370 CHIP
 Interface RS-232 (9.6~115.2Kbps); USB 1.1 ( HID-KBW, HID-POS )
 Image Sensor  752× 480 CMOS
 Symbologies 2D: PDF417, Data Matrix, QR Code
 1D: EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN,
       Codabar, Code 128, Code 93, ITF-6, ITF-14,
       Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5,
       Matrix 2 of 5, GS1 Databar (RSS-Expand,
       RSS-Limited, RSS-14), Code 39, Code 11,
       MSI-Plessey, Plessey
 Scan Mode   Sense mode
 Resolution  10mil
 Light Source White LED
 Scan Window 38.3mm*60.4mm
 PCS  ≥ 30%
 FOV

 Diagonal: 85°,

 Horizontal: 63.7°

 Vertical: 70°

 Ambient Light 0 ~ 100,000 LUX
 Power Consumption 1.75W (max.)
 Power Adapter

 Output: DC5V, 0.5A,

 Input: AC100~240V, 50~60Hz

 Notification  Beep
 Dimensions  71mm(L) X 61mm (W) X 50mm(H)
 Weight  300g
 Operating Temperature -10 ℃ to + 50 ℃
 Storage Temperature -20 ℃ to + 60 ℃
 Humidity 5% - 95% ( non-condensing )
Certification FCC Part15 Class B, CE EMC Class B

Certifications



Company Shows

RAKINDA is a company committed to the development up to bar code technology at the core of the automatic identification system integration organizations, enjoyed several years of industry experience and excellent reputation, in Shenzhen and Hong Kong branches, and has a very skillful, experienced, innovative R & D and after-sales technical support service team.

Rakinda Group, the manufacturer of barcode scanner module, was established in 2000. We have offices in Guangzhou, Shenzhen, Hongkong, Xiamen, Suzhou and Beijing. And we have been supplying the barcode scanner module for Walmart, Carrefour and Foxconn etc.We have a strict QC on every procedure of production, to make sure the quality of products.

We apply the ROHS standard to warehouse management so that we can clearly identify different kinds of material and category to meet the international ROHS standard of inventory. Lead-free production process is also one of our methods to meet environmental responsibility.

Trade Shows

Barcode Scanner FAQ

Q1: Can I get some samples? are they free?

A1: Of course, but samples are not free.

Q2: What's the delivery time?

A2: Depend on product and quantity of your order,sample could be sent to you in 3 work days after receiving balance.

Q3: What about payment?

A3: Payment terms: T/T,West Union and L/C etc.

Q4: Can you list the product of your company?

A4: Barcode Scanner Module, Desktop Barcode Scanner, Handheld Barcode Scanner, Portable Barcode Scanner Module, Bluetooth RFID Scanner, POS Terminal, Android Mainboard etc.

Q5: What's the OS of the POS?

A5: Android and Windows,details please refer to the technical data of the Product.

Q6: Where can we download the SDK/user manual for some of your products?

A6: SDK/User manual will be sent to you by email after the sample order.

Q7: Warranty time?

A7: 1 year

Q8: Do you provide Evaluation Kit for testing barcode scanner module?

A8:  Yes, but you need to pay for EVK separately.

Q9: Product OEM?

A9: Yes, but it requiries the certain MOQ and the cost need to be added separately.

Q10: Customer service?

A10: Any questions of product after your receipt, please contact us,we'll reply you in 24 hours.
